SE0X-LB LoRaWAN® Converter for Soil Sensor

https://www.aiotkart.com/web/image/product.template/17769/image_1920?unique=bac37b3

The Dragino SE0X-LB LoRaWAN® Converter for Soil Sensor is an advanced agricultural IoT device designed to collect soil data from up to four external sensor probes and transmit it over a LoRaWAN® network. It is engineered for long-term soil monitoring in precision farming applications, especially in saline-alkali and loamy soils.

The SE0X-LB measures Soil Moisture, Soil Temperature, and Soil Electrical Conductivity (EC). It uses the FDR (Frequency Domain Reflectometry) method to calculate soil moisture with temperature and EC compensation for improved accuracy. The device is factory-calibrated for mineral soil types to ensure reliable readings.

With ultra-low power consumption and long-range LoRa wireless technology, the SE0X-LB enables data transmission over kilometers while maintaining battery life for several years. It supports Bluetooth v5.1 configuration and wireless OTA firmware updates for easy setup and remote management.

Each unit is preloaded with unique LoRaWAN® OTAA keys for secure network registration and automatic connection upon power-up.

Login | Register to see price

Not Available For Sale

(₹ 0.00 / UNIT)
9 people are viewing this right now

This combination does not exist.

Contact Us

  • LoRaWAN® 1.0.3 Class A compliant
  • Supports up to 4 external soil sensor probes (3.5m cable length)
  • Measures Soil Moisture (FDR method)
  • Measures Soil Temperature (RTD calibrated)
  • Measures Soil Conductivity (EC with temperature compensation)
  • Factory calibrated for mineral soil type
  • Ultra-low power consumption
  • Bluetooth v5.1 configuration support
  • Remote configuration via LoRaWAN® downlink
  • Wireless OTA firmware updates
  • AT command support
  • IP66 waterproof enclosure
  • Powered by 8500mAh Li/SOCl2 battery

Electrical Characteristics

  • Power Supply: Built-in 8500mAh Li/SOCl2 battery
  • Supply Voltage: 2.5V ~ 3.6V
  • Operating Temperature: -40°C to 85°C

Soil Moisture

  • Range: 0 – 100.00 V/V %
  • Resolution: 0.01 V/V %
  • Accuracy:
    • ±3% (0–53%) V/V %
    • ±5% (>53%) V/V %
  • Measurement Method: FDR with temperature & EC compensation

Soil Temperature

  • Range: -40.00°C ~ 85.00°C
  • Resolution: 0.01°C
  • Accuracy:
    • <0.3°C (-10°C ~ 50°C)
    • <0.6°C (other ranges)
  • Measurement Method: RTD, calibrated

Soil Conductivity (EC)

  • Range: 0 – 20000 µS/cm (25°C) (0–20.0 EC)
  • Resolution: 1 µS/cm
  • Accuracy: 2% FS
  • Measurement Method: Conductivity with temperature compensation

LoRa Specifications

  • Frequency Range: 862 ~ 1020 MHz
  • Max RF Output: +22 dBm
  • RX Sensitivity: Down to -139 dBm
  • Supported Bands: CN470 / EU433 / KR920 / US915 / EU868 / AS923 / AU915 / IN865

Power Consumption

  • Sleep Mode: 5µA @ 3.3V
  • LoRa Transmit Mode:
    • 125mA @ 20dBm
    • 82mA @ 14dBm

Physical Specifications

  • Enclosure Protection: IP66
  • Device Size: As per manufacturer specification
  • Device Weight: As per manufacturer specification

The SE0X-LB is suitable for:

  • Smart Agriculture
  • Precision Farming
  • Saline Soil Monitoring
  • Irrigation Control Systems
  • Crop Health Monitoring
  • Agricultural Research
  • Greenhouse Automation

SE0X-LB is calibrated for saline-alkali soil and loamy soil. If users want to use it for other soil, they can calibrate the value in the IoT platform base on the value measured by saline-alkali soil and loamy soil. The formula can be found at this link.

Documents

SE0X-LB_User_Manual

Download

SE0X-LB_Datasheet

Download

SE0X-LB_Firmware

Download
