SE0X-LB LoRaWAN Converter for Soil Sensor

The Dragino SE0X-LB is a LoRaWAN® soil sensor transmitter designed for smart agriculture applications, capable of connecting up to 4 external soil sensor probes. It collects soil moisture, soil temperature, and soil electrical conductivity (EC) data using FDR technology with temperature and EC compensation. Factory-calibrated for mineral soils, it ensures accurate, long-term soil monitoring with ultra-low power LoRaWAN communication.

Key Specifications

• Protocol: LoRaWAN v1.0.3 Class A

• Supported Probes: Up to 4 external soil probes (3.5 m cable length each)

• Measured Parameters:

  • Soil Moisture: 0–100% V/V

  • Soil Temperature: –40 °C to +85 °C

  • Soil Conductivity: 0–20,000 µS/cm (0–20 EC)

• Measurement Technology:

  • Moisture: FDR with temperature & EC compensation

  • Temperature: RTD, factory calibrated

  • Conductivity: Temperature-compensated EC

• Frequency Bands: CN470 / EU433 / KR920 / US915 / EU868 / AS923 / AU915 / IN865

• Configuration: Bluetooth v5.1 & LoRaWAN remote configuration

• Firmware: Wireless OTA update

• Enclosure: IP66 waterproof

• Power Supply: 8500mAh Li-SOCl₂ battery

• Battery Life: Several years (typical)

• Operating Temperature: –40 °C to +85 °C

Applications

Precision agriculture, multi-point soil monitoring, irrigation optimization, greenhouse farming, and soil health analysis across large agricultural fields.

USER MANUAL:

SE0X-LB_User_Manual

DATA SHEET:

SE0X-LB_Datasheet

FIRMWARE:

SE0X-LB_Firmware
