RS485W-LB-M12 RS485 to LoRaWAN Converter
10 Units sold in last 24 hours
The Dragino RS485W-LB-M12 is an industrial RS485 to LoRaWAN converter designed to wirelessly connect RS485 devices to LoRaWAN networks. Equipped with a robust M12 industrial connector and IP67 waterproof enclosure, it is ideal for outdoor and harsh industrial environments. The device polls RS485 sensors (including Modbus RTU devices), processes the data, and transmits it over long-range, low-power LoRaWAN communication. It is battery-powered for long-term, maintenance-free operation.
Key Specifications
Protocol: LoRaWAN v1.0.3 Class A
Interface: RS485 via M12 industrial connector
Supported Protocols: Modbus RTU and custom RS485 commands
Frequency Bands: CN470 / EU433 / KR920 / US915 / EU868 / AS923 / AU915 / IN865 / RU864 / MA869
RX Sensitivity: up to –139 dBm
Power Supply: 8500mAh Li-SOCl₂ battery
Battery Life: Up to 5 years (typical)
Operating Temperature: –40°C to +85°C
Configuration: Bluetooth v5.1 & LoRaWAN downlink
Firmware: Wireless OTA update
Enclosure: IP67 waterproof, industrial-grade
Uplink: Periodic polling or event-based
Applications
Industrial RS485 device integration, Modbus sensor networking, smart agriculture, smart metering, water and energy monitoring, building automation, smart city infrastructure, and remote industrial data acquisition.
USER MANUAL:
DATA SHEET:
FIRMWARE:
