DLOS8N-EC25 Outdoor LoRaWAN Gateway
The Dragino DLOS8N-EC25 is an industrial-grade Outdoor LoRaWAN Gateway built for long-range, high-reliability IoT deployments across India. Designed with an SX1302 LoRaWAN concentrator, the DLOS8N bridges LoRa wireless networks to IP infrastructure via Ethernet, WiFi, 3G, or 4G connectivity. Fully compatible with the LoRaWAN protocol, it supports both Semtech UDP Packet Forwarder and LoRaWAN Station connections, making it suitable for integration with public or private LoRaWAN servers. With IP65-rated enclosure, PoE support, built-in GPS, and lightning protection, this gateway is ideal for harsh outdoor environments. The DLOS8N-EC25 can also directly communicate with ABP LoRaWAN end nodes without requiring a LoRaWAN server, enabling flexible Industrial IoT architectures. AIoTkart is an Authorized Dragino Distributor in India, supplying genuine DLOS8N gateways with PAN-India delivery and deployment support.
Key Features
Dragino DLOS8N-EC25 Outdoor LoRaWAN Gateway
SX1302 + 2 × SX1250 LoRaWAN concentrator
Multi-channel LoRaWAN support
Supports Semtech UDP & LoRaWAN Station
Direct communication with ABP LoRaWAN nodes
Ethernet, WiFi, 3G & 4G connectivity
IEEE 802.3af PoE support
IP65 rated outdoor enclosure
Built-in GPS for timing & location
Lightning protection & industrial design
Auto-provisioning for mass deployment
Remote monitoring via Web GUI & SSH
Technical Specifications
LoRaWAN Performance
Sensitivity: Up to -140 dBm
49 LoRa demodulators + 1 (G)FSK demodulator emulation
10 programmable parallel demodulation paths
70 dB CW interferer rejection @ 1 MHz offset
Dynamic Data Rate (DDR) adaptation
Dual TX/RX front-end interfaces
Antenna diversity / dual-band operation
LoRa Concentrator: SX1302 + 2 × SX1250
Interfaces
1 × 10/100M RJ45 Ethernet Port
WiFi 802.11 b/g/n
USB 2.0 Host Port
Mini-PCIe Connector
LoRaWAN Wireless
External Fiber Glass Antenna
Power & Environmental
Power Input: 12–24V DC, 2A
IEEE 802.3af PoE (37–57V DC)
Power Consumption: 12V, 300–500mA
Operating Temperature: -20°C to 85°C
IP65 Outdoor Protection
Lightning Protection
Physical Specifications
Package Size: 490 × 120 × 190 mm
Net Weight: 1.7 kg
Volume Weight: 2.5 kg
Package Includes
1 × Dragino DLOS8N-EC25 Gateway
1 × Fiber Glass Antenna
1 × Power Adapter
Environmental packaging
Applications
The Dragino DLOS8N-EC25 Outdoor LoRaWAN Gateway is suitable for large-scale outdoor Industrial IoT deployments in India, including:
Industrial automation and manufacturing zones
Commercial infrastructure and facility monitoring
Smart buildings and institutional campuses
Water management and utility networks
Cold chain logistics hubs
Smart metering infrastructure
Agriculture and irrigation systems
Smart city and public infrastructure projects
Logistics and supply chain monitoring
Why Buy from AIoTkart
Authorized Dragino Distributor in India
100% genuine Dragino industrial equipment
PAN-India shipping and logistics support
Bulk and institutional order handling
Pre-sales architecture consultation
Deployment support for industrial and government projects
Frequently Asked Questions
1. Where can I buy Dragino DLOS8N-EC25 Outdoor LoRaWAN Gateway in India?
You can purchase the genuine Dragino DLOS8N-EC25 in India from AIoTkart, an Authorized Dragino Distributor offering PAN-India shipping, bulk pricing, and technical support for Industrial IoT deployments.
2. Can the DLOS8N-EC25 be deployed for large outdoor LoRaWAN networks in India?
Yes. With its SX1302 concentrator, IP65 enclosure, PoE support, and high sensitivity performance, the DLOS8N-EC25 is ideal for large outdoor LoRaWAN networks across industrial zones, utilities, and smart city infrastructure.
3. Does the DLOS8N-EC25 require a LoRaWAN server for communication?
Not necessarily. The DLOS8N-EC25 can directly communicate with ABP LoRaWAN end nodes without a LoRaWAN server, or it can integrate with public or private LoRaWAN platforms using Semtech UDP or LoRaWAN Station.
Useful Links
USER MANUAL: DLOS8N-EC25_User_Manual
DATA SHEET: DLOS8N-EC25_Datasheet
FIRMWARE: DLOS8N-EC25_Firmware
